型号 Model | TC-D-60 | TC-D-80 | TC-D-100 | TC-D-150 | TC-D-200 | |||
介质 Liquid Medium |
导热油、乙二醇、燃油、滑油、液压油等(倾点及沸点需满足设备使用范围) | |||||||
Heat conducting oil,ethylene glycol,fuel oil,lubricating oil,hydraulic oil,etc | ||||||||
(pour point and boiling point should meet the application range of the equipment) | ||||||||
工作室尺寸(mm) Test Space Dimensions |
W | 800 | 900 | 900 | 1200 | 1200 | ||
D | 800 | 900 | 900 | 1500 | 1500 | |||
H | 1650 | 1650 | 1650 | 1850 | 1850 | |||
低温度 Min Temp. | -30℃,-40℃,-60℃,-70℃~RT | |||||||
高温度 Max Temp. | RT~+100℃,+200℃,+250℃ | |||||||
温度波动范围 Temp.Fluctuation | ≤±0.5℃ | |||||||
冷却方式 Type of Cooling | 风冷Air-Cooled | 水冷 Water-Cooled | ||||||
制冷方式 Cool Mode | 单级制冷/双极制冷 Single stage refrigeration/Two-stage cascade refigeration | |||||||
循环控制 Cycle Control | 导热油内循环/介质外循环 Heat conducting oil internal circulation/External circulation of dielectric | |||||||
流量 Flow Range | 0~50L/Min, 100L/Min, 150L/Min, 200L/Min, 250L/Min, | |||||||
压力 Pressure Range | 0~1.0bar,2.0bar,3.0bar | |||||||
通讯方式 Communication Methods |
RS232 | |||||||
Ethernrt | ||||||||
Modbus | ||||||||
Optional:RS485,Profibus | ||||||||
额定电压 Nominal Voltage | AC380V±10%,50Hz | |||||||
功率Power(KW) | 12 | 16 | 20 | 30 | 40 | |||
重量Weight(KG) | ≤510 | ≤540 | ≤585 | ≤685 | ≤1020 |
备注
1.设备性能在环境温度+25℃,相对湿度65%RH下,无负载所测。The performance vulues refer to environmental +25℃ 65%RH,no loading.
2.外形尺寸未包含局部突出部分。The ledge is not included in the overall dimensions.
