型号 Model | WTC-12 | WTC-15 | WTC-18 | WTC-25 | WTC-35 | WTC-45 | |
工作室容积(立方米)Test Space Volume (m³) | 12 | 15 | 18 | 25 | 35 | 45 | |
工作室尺寸(mm) Test Space Dimensions |
W | 3000 | 3000 | 3000 | 3000 | 3600 | 4000 |
D | 2000 | 2500 | 3000 | 4000 | 4600 | 5100 | |
H | 2000 | 2000 | 2000 | 2100 | 2100 | 2200 | |
温度范围 Temp. Range | -70℃~+85℃(150℃) | ||||||
温度波动范围 Temp. Fluctuation | ≤±0.5℃ | ||||||
温度均匀度 Temp. Uniformity | ≤2.0℃ | ||||||
升温速率 Heating Rate | 1.0~3.0℃/min (或根据用户要求/or according to the customer's requirement) | ||||||
降温速率 Cooling Rate | 0.7~1.2℃/min (或根据用户要求/or according to the customer's requirement) | ||||||
湿度范围 Humidity R ange | 10%RH~98%RH | ||||||
湿度误差 Humidity Diviation | +2/-3%RH | ||||||
制冷方式 Type of Cooling | 风冷/水冷 Air- cooled/Water-cooled | 水冷 Water-cooled | |||||
额定电压 Nominal Voltage | AC380V ±10%,50Hz | ||||||
功率 Power (kW) | ≤30 | ≤35 | ≤42 | ≤50 | ≤60 | ≤70 |
备注
1.设备性能在环境温度+25℃,相对湿度65%RH下,无负载所测。The performance vulues refer to environmental +25℃ 65%RH,no loading.
2.外形尺寸未包含局部突出部分。The ledge is not included in the overall dimensions.
3.根据用户要求定制特殊尺寸。Special size can be customized according to user's requirement.
